TSE : TOWER STRUCTURAL ENGINEERING SOFTWARE
INTEGRATED STRUCTURAL ANALYSIS AND DESIGN SOFTWARE
TSE SOFTWARE
The Tower Structural Engineering Software is an integrated analysis and design software for structural engineering. The software accounts for advanced structural analysis and design of steel latticed transmission towers, electrical substations, tubular poles, multi-poles frames and telecommunication structures such as self-supporting towers and guyed masts.
This engineering software solution is used worldwide by several notable international companies in production work for building innovative tower structures. The TSE is a robust and reliable structural software based on more than 34 years of Research and Development.
The advanced structural analysis of the TSE software allows the user to achieve specialized analyses crucial to any projects related to the construction industry.
TSE SOFTWARE
FULLY INTEGRATED TECHNOLOGY
Enhance productivity with an integrated technology.
DESIGN CODES
Profit from a technology tailored to enhance the application of the supported codes.
ADVANCED FEATURES
Ensure better productivity to achieve complex structural projects.
OUTSTANDING TECHNICAL SUPPORT
Take advantage of support provided by structural engineers.
Free Demo Video
See for yourself the powerful features of the TSE Tower Structural Engineering – Advanced Analysis and Design software.
ANALYSIS SPECIFICATIONS
SIESMIC AND DYNAMIC ANALYSIS
Automated simplified method of the building codes (NBCC and IBC)
Seismic response spectrum, seismic time-history and dynamic time-history analysis
Customized response spectrums and accelerograms
Fully customizable analysis parameters
Maximal response using CQC and SRSS methods
Automated or user defined damping
Graphical display of response spectrums and accelerograms
User defined incidence angle of seismic loads and vertical components
Customized analysis and output time steps
Time refined results can be provided for selected parts of the models
Automated or custom determination of the signs of deformations provided by the maximum response methods
Additional masses can be added to the model by way of static loads
Seismic loads (spectrum or accelerogram) and dynamic loads (sinusoidal, general load functions and random load functions)
Multiple seismic and dynamic loads can be combined together in a single analysis
Base shear calibration according to the selected building code
Possibility to define several seismic loads and account for eccentricities between the center of stiffness and the center of mass
Graphical display of the center of stiffness and the center of mass and seismic forces at floors
Account for accidental eccentricities
Account for the I, F and R coefficients of the NBCC and IBC code in spectral and time-history analysis
Seismic response spectrum, seismic time-history and dynamic time-history analysis
Customized response spectrums and accelerograms
Fully customizable analysis parameters
Maximal response using CQC and SRSS methods
Automated or user defined damping
Graphical display of response spectrums and accelerograms
User defined incidence angle of seismic loads and vertical components
Customized analysis and output time steps
Time refined results can be provided for selected parts of the models
Automated or custom determination of the signs of deformations provided by the maximum response methods
Additional masses can be added to the model by way of static loads
Seismic loads (spectrum or accelerogram) and dynamic loads (sinusoidal, general load functions and random load functions)
Multiple seismic and dynamic loads can be combined together in a single analysis
Base shear calibration according to the selected building code
Possibility to define several seismic loads and account for eccentricities between the center of stiffness and the center of mass
Graphical display of the center of stiffness and the center of mass and seismic forces at floors
Account for accidental eccentricities
Account for the I, F and R coefficients of the NBCC and IBC code in spectral and time-history analysis
LOADS AND LOAD COMBINATIONS
The software allows the user to create load combinations.
A load combination results in an algebric combination of distinct basic loads.
Each basic load is multiplied by a load factor. The resulting load combination acts on the structure to generate a specific structural response.
The load combination wizard in the program also allows creating load patterns.
The load combination wizard generates load combinations according to NBCC, UBC, ASCE 7, BOCA, Eurocode and ECC.
Loading for joints, members including concentrated, uniform, trapezoidal and thermal loads.
Pressure or concentrated floor loads with two-way, one-way and truss distribution using triangular or quadrilateral surfaces.
Pressure or concentrated loads on finite element plates.
Gravity loads in any global direction calculated by the program.
Imposed displacements at any joint. User defined load combinations.
A load combination results in an algebric combination of distinct basic loads.
Each basic load is multiplied by a load factor. The resulting load combination acts on the structure to generate a specific structural response.
The load combination wizard in the program also allows creating load patterns.
The load combination wizard generates load combinations according to NBCC, UBC, ASCE 7, BOCA, Eurocode and ECC.
Loading for joints, members including concentrated, uniform, trapezoidal and thermal loads.
Pressure or concentrated floor loads with two-way, one-way and truss distribution using triangular or quadrilateral surfaces.
Pressure or concentrated loads on finite element plates.
Gravity loads in any global direction calculated by the program.
Imposed displacements at any joint. User defined load combinations.
COMPREHENSIVE STRUCTURAL ANALYSIS OPTIONS
FEA Finite Elements Analysis, Static Analysis, Linear and Nonlinear Analysis, P-Delta Analysis, Natural Frequency Analysis, Static Equivalent, Seismic and Dynamic Analysis, Time-History Analysis, Modal Analysis, Spatial Objects and Spatial Loads, Buckling Analysis, Spectral Analysis, Advanced Section Stress, Torsion and Warping, Built Up Sections, Catenary Cables, Diaphragm Analysis, Notional Horizontal Loads, Loads and Load Combinations.
SPATIAL OBJECTS AND SPATIAL LOADS
Spatial objects are used to model non-structural secondary elements attached to the structure. These elements add no stiffness to the existing model. Loads applied to spatial objects are transferred to the structure through one or more attach joints. The loads are transferred using a “rigid plate” approach.
Concentrated, pressure and wind loads may be applied to spatial objects. The figures below shows a spatial object loaded vertically and horizontally attached to a cantilever column. Also, it shows the deformations and biaxial moments induced by the loads transferred by the spatial object.
CATENARY CABLES
The catenary cable element is a highly non-linear element used to model the catenary behavior of a cable suspended between two points under the effect of its self-weight. This formulation accounts for the non-linearity due to large displacements.
A cable has no bending, shear, compression or torsion stiffness. Due to this fact, the fixities at the ends are ignored; the cable is always treated as member acting in tension only. In the interface of the TSE, the user can create a catenary cable by associating a cable type section to a member.
DIRECT ANALYSIS METHOD
Direct Analysis Method (DAM) available for AISC 360-16 and AISC 360-10 standards. The options for the Stability Design Method are Direct Analysis Method (DAM) and Effective Length Method (kL).
TORSION AND WARPING
The TSE software considers restrained warping for the torsion of thin-wall open sections. Notice that this phenomenon is not included in most commonly used frame analysis programs. Almost all frame programs in practice use St-Venant torsion theory ignoring the effects of restrained warping.
ANALYSIS ANIMATION FEATURE
ANIMATION FEATURE
The TSE software allows users to animate results from different types of analysis such as:
-Static Linear Analysis
-Static P-Delta Analysis
-Buckling Analysis
-Natural Frequencies Analysis
-Seismic and Dynamic Analysis
The results are scaled by a linearly increasing factor until the unity factor is reached. The user can detect which parts of the model undergo the most displacements or internal forces by seeing the variation of intensity across the model.
TIME HISTORY
The animation function displays every saved time-step to provide an accurate representation of the displacements, velocities, accelerations and internal forces acting on the structure.
This will provide the user a better understanding of the structure behavior during the dynamic event, such as finding the critical time of the dynamic loading.
STATIC LINEAR AND P-DELTA ANALYSIS
With the TSE software, users are able to animate various static linear and P-Delta analysis results such as the:
-Structure displacements
-Internal forces
-Stresses
-Support reactions.
FREQUENCY & BUCKLING
The frequency and buckling analysis provide multiple mode shapes describing multiple behaviors of the structure. With large models, the animation is helpful to discern and understand the mode shapes. It is easier to determine if the buckling mode is a local or global phenomenon. It also provides a very accurate interpretation of the participating mass of each mode in a seismic spectral analysis.
Animating the envelopes helps minimizing the amount of information on the screen. The user can focus on the most critical regions of the model.
MODELING FEATURES
Local coordinate systems
Linear or circular lines of constructions for model creations
Automated commands for model creation such as move, rotate, extrude, copy, attach, subdivide and others
Models can be edited either graphically or by means of spreadsheets
Element can be created in batch or one by one
Elements of the models can be selected either graphically or according to a set of criterions
Persistent groups of selected objects can be created and edited graphically or by means of spreadsheets
Definition of physical members
Selection and edition of physical members
Definition of loading surfaces
Multiple edition grids with user defined spacing, angles and labels
Powerful edition and automatic generation tools
Members can be subdivided in any number of equal segments or at specific positions
EXTENSIVE PROFILE TYPES AND LIBRARIES
Standard sections (CISC, AISC and European)
Custom section libraries
Non-standard sections (over 30 shapes available)
Truss and pre-tensioned cable sections
User defined section properties
Composite sections are available
Similar connected members can be merged together
Elements of the structure can be renumbered according to several criterions
Element attributes can be set graphically or by means of spreadsheets (sections, analysis parameters, rotation angles, etc.)
Element attributes can be edited in batch or element by element
Loads can be edited graphically or by means of spreadsheets
Contour lines for finite element plates with customized bounds
Wizard based geometry generation
A large number of pre-defined frames
Circular and parabolic arches
Cylinders and cones composed of beams and/or plates
Physical elements concept to group different elements
Surfaces can be used for load transfer and self-weight calculation
Surfaces can be used to simulate diaphragm effects
GEOMETRIC CALCULATOR
Wizard based geometry generation
Large number of pre-defined frames
Over 30 pre-defined trusses
Circular and parabolic arches
Cylinders and cones composed of beams and/or plates
Large number of pre-defined frames
Over 30 pre-defined trusses
Circular and parabolic arches
Cylinders and cones composed of beams and/or plates
DISPLAY FEATURES
The program manages to scale the size of the various pictures including toolbar buttons in order to make the user interface easy to use on every monitor, even on very high resolution monitors.
3D solid display of all section shapes
Ultra-fast 3D visualization in wire frame or solid modes
Customized display of all graphical objects.
Partial model visualization.
Results can be displayed on screen for the whole or a part of the structure.
Results can be displayed for each element separately by means of graphics and numerical results spreadsheets.
Results can be displayed for a set of elements by means of numerical results spreadsheets.
3D solid display of all section shapes
Ultra-fast 3D visualization in wire frame or solid modes
Customized display of all graphical objects.
Partial model visualization.
Results can be displayed on screen for the whole or a part of the structure.
Results can be displayed for each element separately by means of graphics and numerical results spreadsheets.
Results can be displayed for a set of elements by means of numerical results spreadsheets.
unit systems
Metric, imperial and mixed units systems are allowed and can be modified at any time. Reports are printed according to any unit system.
Graphical display of seismic and dynamic analysis results
Model size limited only to the physical capacity of the computer.
Objects transparency for various components such as current selection, solid members, plates, surfaces, spatial objects, panels.
The level of transparency may be customized for each type of object from the Display Options command.
Functionalities of the GSE program allow to generate automatically detail elements in an automatically generated mesh perimeter.
These functionalities are specifically related to the refinement area, the opening, the linear constraint and the punctual constraint.
All detail elements added to the GSE model will be automatically connected to the finite element mesh.
The mesh perimeter will also connect any elements already in the model to the mesh perimeter automatically if they are in the plane of the mesh contour.
Objects transparency for various components such as current selection, solid members, plates, surfaces, spatial objects, panels.
The level of transparency may be customized for each type of object from the Display Options command.
Functionalities of the GSE program allow to generate automatically detail elements in an automatically generated mesh perimeter.
These functionalities are specifically related to the refinement area, the opening, the linear constraint and the punctual constraint.
All detail elements added to the GSE model will be automatically connected to the finite element mesh.
The mesh perimeter will also connect any elements already in the model to the mesh perimeter automatically if they are in the plane of the mesh contour.
Comprehensive Reports Provided
Results can be visualized either graphically or numerically.
Input data and results may be printed for the whole structure or partial structures using a graphical selection or a range of elements.
Customized list of input data and results to be printed.
Input data and results may be printed for the whole structure or partial structures using a graphical selection or a range of elements.
Customized list of input data and results to be printed.
Reports are available in several formats including SAFI™ reports, Microsoft Excel worksheets, Microsoft Access databases and ASCII text files.
All graphics can be printed or copied to the clipboard for use in external programs.
All graphics can be printed or copied to the clipboard for use in external programs.
FILE IMPORT AND DATA EXCHANGE
IFC (INDUSTRY FOUNDATION CLASSES)
The integration of IFC in the GSE program enables importation of models from a large number of architectural and structural software.
IFC (Industry Foundation Classes) is an open and neutral data format allowing the definition of related classes to all construction objects. It is dedicated to the building sector and aims to software interoperability (all editors, all applications).
IFC is the most widely used protocol for information exchange and sharing between different platforms of BIM (Building Information Modeling).
The integration of IFC in the GSE program enables importation of models from a large number of architectural and structural software.
IFC (Industry Foundation Classes) is an open and neutral data format allowing the definition of related classes to all construction objects. It is dedicated to the building sector and aims to software interoperability (all editors, all applications).
IFC is the most widely used protocol for information exchange and sharing between different platforms of BIM (Building Information Modeling).
AutoCAD interface to import and export models by way of a DXF file.
The SDNF (Steel Detailing Neutral File) interface exports beams, columns and braces to SDNF compatible detailing software.
The KISS (Keep It Simple Steel) interface exports beams, columns and braces to KISS compatible estimation softwares.
IFC-Architecture interface for importing models from Revit or other IFC compliant programs.
If required, members subdivision and account for physical elements will be carried out automatically The solid view of the structure may also be exported when exporting to AutoCAD.
The SDNF (Steel Detailing Neutral File) interface exports beams, columns and braces to SDNF compatible detailing software.
The KISS (Keep It Simple Steel) interface exports beams, columns and braces to KISS compatible estimation softwares.
IFC-Architecture interface for importing models from Revit or other IFC compliant programs.
If required, members subdivision and account for physical elements will be carried out automatically The solid view of the structure may also be exported when exporting to AutoCAD.
TSE SOFTWARE PACKAGE
TSE TELECOM
Design of steel telecommunication structures, self-supporting towers, guyed masts according to ANSI/TIA-222-H and CSA S37-18.
GET IN TOUCH WITH US
Complete this form to have a TSE expert contact you to answer all questions you may have and discuss any of your needs.
CONTACT
- SAFI Quality Software, Inc.
-
CANADA CORPORATE OFFICE
3393 Sainte-Foy Road, Quebec City
QC, G1X1S7
CAN - [email protected]
- (TOLL FREE USA & CAN) 1 800.810.9454
- + 1 418.654.9454
- © 2020 SAFI QUALITY SOFTWARE, INCORPORATED. ALL RIGHTS RESERVED.
